Vending Machines

SKU: KF10X22

Available for distribution: true
Available for retail: true
Indicative Retail Price: $2100 USD

Description

22-inch touch screen vending machines are ideal for occasions where a large screen helps operators show advertisements, run marketing campaigns, or meet rules in regions where additional information has to be shown to consumers, such as nutrition information.

Because of the extended space behind the touch screen, this kind of vending machine is also popular for applications where heavy customization is required, especially industrial vending or vending machines with an HID card reader.

KF10X22 specifications

Every value below is the published configuration for this model. Anything not listed is specified on the quotation.

Specification	KF10X22
Model	KF10X22
Dimensions (W × D × H)	1,310 × 820 × 1,975 mm
Layouts	5-wide (standard, 10 selections per row) or 4-wide (8 per row)
Trays	5 or 6
Selections	Up to 60 in the standard 5-wide, 6-tray layout
Screen	22-inch touchscreen, with shopping cart
Payment	MDB cashless (credit card reader), MDB note reader, MDB coin mech
Temperature	Refrigerated (R290 or R134a) or ambient
Base	Fixed legs or industrial castor wheels
Internal space	Extended space behind the screen for HID card readers, extra sensors and custom dispensing mechanisms
Indicative price	From USD 2,100, before freight, duties and installation
Sold through distributors	Yes

No weight is published for the KF10X22 as a model. Ask for it, and for the packing dimensions, on the quotation.

Who the KF10X22 is for

• Advertising and promotion. The 22-inch screen shows product images, brand content and campaigns between sales.
• Markets that require on-screen information. The large screen holds a full nutrition panel alongside advertising space, and multi-language interfaces. See nutrition information.
• Industrial vending. The KF10X22 is a common base platform for our industrial vending deployments, configured as a tool & parts vending machine for automated tool crib management, or as a point-of-use MRO station on the production floor.
• Fresh food, drinks and larger ranges. A full-size refrigerated cabinet for high-volume sites and mixed product ranges.

Configuration options

Payment

The KF10X22 takes an MDB cashless card reader, an MDB note reader and an MDB coin mech. Cashless terminals such as Nayax, Cantaloupe or VendCoin from our Australian software partner Vending on Track are supported over the standard MDB interface, so you can keep an existing processor. Item-level reporting comes from the machine’s own telemetry, not from the payment terminal, so every order records which product was sold even on a card sale. See payment methods.

Access control and industrial options

For workplace issue, staff log in with an RFID card or PIN, and the machine checks their entitlement or quota before it releases the item. The space behind the screen takes HID card readers and other hardware. These options are specified per project:

• Per-cell weight sensing, optional and fitted at the factory per cell, to confirm each dispense. It cannot be retrofitted, so specify it at order. See weight sensor tracking.
• ServiceNow integration, which logs dispense events as ITSM tickets. See ServiceNow integration.
• Biometric login, as an option at extra cost, quoted per project.

Screen features

• Shopping cart. Customers buy several items in one transaction. See shopping cart.
• Advertising content between sales, and multi-language interfaces.

Refrigeration

Choose ambient, or refrigerated with R290 or R134a refrigerant; refrigerated costs more. Refrigerated KioskForce machines have a health-control block that stops sales when the cabinet goes out of temperature range, set to your food-safety rules.

Specifying a refrigerated build? The EU now regulates refrigerated vending machines under Ecodesign — including an 8-year spare-parts requirement and the shift from R134a to R290 — which changes how you should lock the refrigerant and serviceability spec. Read the EU Ecodesign guide for refrigerated vending machines.

Selling fresh or chilled food from this machine? See the guide to refrigerated vending machines for fresh and healthy food.

Coils and layout

The coil type and pitch are chosen per selection so that each product drops reliably. See coil options and the planogram configurator.

Fitting it into the building

The KF10X22 is 1,310 mm wide, 820 mm deep and 1,975 mm tall. At 820 mm deep it will not pass an 815 mm (32-inch) clear door opening, the minimum in the 2010 ADA Standards, without a wider door or removing the door leaf. Check that the final position is wide enough for the cabinet plus room to open the door, and measure every door and lift on the route.

When the KF10X22 is the wrong choice

• The position is narrow. The KF6X10 is 616 mm wide.
• You do not need the large screen or extra internal space. The BG10X10 is 200 mm narrower, has a 10-inch sidecar touchscreen and starts from USD 1,200.
• Items are bulky, fragile or come back. Locker cells suit them better than coils. See the L180-10C locker and PPE vending machines with hybrid return cells.
• There is no floor space. A compact wall-mount vending machine mounts on the wall.

Price, lead time and ordering

• Price: from USD 2,100 per unit at the published indicative price, before freight, duties and installation. Base industrial PPE, tool and MRO machines start from the same USD 2,100. At up to 60 selections, that is about USD 35 per selection. See vending machine cost.
• Minimum order: modified standard models (colour, branding, payment configuration) can be ordered as a single unit. Fully custom designs with a new enclosure or custom software typically start at 10 units.
• Lead time: 4–6 weeks to build a modified standard model, 8–12 weeks for a full custom design, plus shipping.
• Power and certification: built to the electrical supply of the destination market. Tell us the market at quotation and we confirm which certification marks and test reports come with the build.
• Warranty and support: 12-month standard warranty covering manufacturing defects. Support is by email, or through the local distributor where one supplied the machine; that distributor also handles warranty and service. On-site installation is optional and, in some regions, provided through a local distributor.

Frequently asked questions

What makes the KF10X22 different from other full-size vending machines?

The KF10X22 has a 22-inch touchscreen, the largest of the standard floor-standing vending machine models (the KF6X10 and BG10X10 have 10-inch screens), for advertising, marketing campaigns, nutrition information and multi-language interfaces. The extended space behind the screen also accommodates HID card readers, additional sensors and custom dispensing mechanisms, which is why it is a common base platform for industrial vending deployments.

What payment methods does the KF10X22 support?

MDB cashless (credit card reader), MDB note reader and MDB coin mechanism.

Can the KF10X22 be refrigerated?

Yes. It is available in refrigerated (R290 or R134a) or ambient configuration, in 5-wide or 4-wide layouts with 5 or 6 trays.

How much does the KF10X22 cost?

The KF10X22 has a published indicative starting price of USD 2,100 per unit, the same starting price as KioskForce’s base industrial PPE, tool and MRO machines. Freight, duties and installation are extra, and refrigeration, payment hardware, sensors and branding move the price.

How many selections does the KF10X22 hold?

The standard 5-wide layout carries 10 selections per row, so up to 60 selections with six trays. The 4-wide layout carries 8 per row, on 5 or 6 trays.

Why is the KF10X22 wider than the BG10X10?

Both are 820 mm deep and 1,975 mm high, but the KF10X22 is 1,310 mm wide against 1,110 mm. The extra 200 mm carries the 22-inch touchscreen and the space behind it for card readers and extra sensors.

Related

• Smart vending machines: how connected vending machines work, with every published price.
• Kiosk vending machines: touchscreen vending platforms compared.
• Vending machine cost: starting prices, what moves the price, and landed cost.

---

Specifications

Refrigeration

• refrigerated (R290)

• refrigerated (R134a)

• ambient

Dimensions: Width: 1310, Depth: 820, Height: 1975

Legs:

• fixed legs

• industrial castor wheels

Trays

• 6

• 5

Width

• 5-wide (standard) (10 selections in row)

• 4-wide (8 selections in row)

MDB Peripherals

• cashless (credit card reader and so on)

• note reader

• coin mech

SKU: KF6X10

Available for distribution: true
Available for retail: true
Indicative Retail Price:

Description

The KF6X10 is built for positions that are too narrow for a standard vending machine. It is a 3-wide cabinet with the same 10-inch touchscreen experience as the larger models: customers browse, add several items to a cart and pay by scanning a QR code. Choose it when floor width is the limit but you still want a screen, chilled stock or more selections than a wall-mount unit holds.

KF6X10 specifications

Every value below is the published configuration for this model. Anything not listed is specified on the quotation.

Specification	KF6X10
Model	KF6X10
Dimensions (W × D × H)	616 × 735 × 1,970 mm
Weight	About 150 kg, before stock
Layout	3-wide, 6 selections per row
Trays	6
Selections	Up to 36 (6 per row × 6 trays)
Screen	10-inch touchscreen, flush with the door frame, with shopping cart
Scanner	QR code scanner embedded in the door frame
Payment	QR code-based payment methods only
Temperature	Refrigerated (R290 or R134a) or ambient
Base	Fixed legs or industrial castor wheels
Price	Quoted per configuration (no published starting price)
Sold through distributors	Yes

Who the KF6X10 is for

• Narrow corridors, break rooms and offices. At 616 mm it is just over half the width of the 5-wide BG10X10 (1,110 mm).
• Cold drinks or chilled food where width is short. It is the narrowest refrigerated touchscreen cabinet in the range, so it fits beside a reception desk or in an alcove. Compact wall-mount units are ambient.
• Sites where customers pay by phone. Payment is QR-based, which suits workplaces, campuses and venues where people already carry a wallet app or a code.

Fitting it through the building

The narrow body helps on the delivery route as well as at the final position. The KF6X10 is 735 mm deep, so it passes through an 815 mm (32-inch) clear door opening, the minimum in the 2010 ADA Standards, with about 80 mm to spare. The 820 mm deep BG10X10 and KF10X22 do not, unless the door is wider or the door leaf is removed. At 1,970 mm tall, check door heights and lift car heights along the route as well. Leave room in front of the machine for the user to stand and for the door to open during restocking.

Configuration options

Payment

The published configuration takes QR code-based payment only. The touchscreen shows a QR code for the order, or the scanner in the frame reads a code from the customer’s phone. Supported QR wallets depend on the market, for example WeChat Pay and Alipay in China, or VendCoin (Tap & Go, QR code) from our Australian software partner Vending on Track in Australia and the UK. See payment methods for how each one works and what happens when the network drops.

Screen features

• Shopping cart. Customers buy several items in one transaction. See shopping cart.
• Nutrition information. On the 10-inch screen this is a nutrition icon with a tap-to-view panel. See nutrition information.
• Code entry. The default homepage can be set to the product selection page or to a code input page, for free-vend or code-release programs.

Refrigeration

Choose ambient, or refrigerated with R290 or R134a refrigerant, to suit the products and the destination market. Refrigerated KioskForce machines have a health-control block that stops sales when the cabinet goes out of temperature range. The threshold, the time allowed above it and how the block is cleared are set to your food-safety rules. If you are selling fresh or chilled food, see the guide to refrigerated vending machines for fresh and healthy food.

Coils and layout

The coil type and pitch are chosen per selection so that each product drops reliably. See coil options and try the layout in the planogram configurator before you request a quotation.

Telemetry and reporting

Sales, stock and faults are reported to the cloud dashboard. Item-level reporting comes from the machine’s own telemetry, so every order records which product was sold, when and at what price.

When the KF6X10 is the wrong choice

• You need cash or a card terminal. The KF6X10 is QR only. The BG10X10 takes QR, MDB cashless and MDB cash, and the KF10X22 takes an MDB card reader, note reader and coin mech.
• You need more than 36 selections. A 5-wide, 6-tray machine holds up to 60.
• There is no floor space at all. A compact wall-mount vending machine mounts on brick or drywall, typically 200–350 mm deep, but it is ambient.
• You want a large screen for advertising. The KF10X22 has a 22-inch touchscreen.

Price, lead time and ordering

• Price: no published starting price; the KF6X10 is quoted per configuration. For comparison, the BG10X10 starts from USD 1,200 and the KF10X22 from USD 2,100. See vending machine cost.
• Minimum order: modified standard models (colour, branding, payment configuration) can be ordered as a single unit. Fully custom designs with a new enclosure or custom software typically start at 10 units.
• Lead time: 4–6 weeks to build a modified standard model, 8–12 weeks for a full custom design, plus shipping.
• Power and certification: built to the electrical supply of the destination market. Tell us the market at quotation and we confirm which certification marks and test reports come with the build.
• Warranty and support: 12-month standard warranty covering manufacturing defects. Support is by email, or through the local distributor where one supplied the machine; that distributor also handles warranty and service. On-site installation is optional and, in some regions, provided through a local distributor.

Frequently asked questions

How narrow is the KF6X10 vending machine?

The KF6X10 is 616 mm wide, 735 mm deep and 1,970 mm high, in a 3-wide layout with six selections per row. It is KioskForce’s narrowest floor-standing touchscreen machine. For comparison, the BG10X10 is 1,110 mm wide and the KF10X22 1,310 mm.

Does the KF6X10 have a touchscreen and QR scanner?

Yes. It has a 10-inch touchscreen with a shopping cart function, flush with the door frame, and a QR code scanner embedded in the frame.

What payment methods does the KF6X10 support?

QR code-based payment methods only. If a site needs coins, notes or a card terminal, the BG10X10 and KF10X22 have published MDB cashless and cash options.

Can the KF6X10 be refrigerated?

Yes. It is available refrigerated with R290 or R134a refrigerant, or ambient. Refrigerated KioskForce machines have a health-control block that stops sales when the cabinet goes out of temperature range.

How many selections does the KF6X10 hold?

Six selections per row on six trays, so up to 36 selections. A 5-wide machine with six trays, such as the BG10X10 or KF10X22, holds up to 60.

How much does the KF6X10 cost and how long does it take?

KioskForce does not publish a starting price for the KF6X10; it is quoted per configuration. Modified standard models can be ordered as a single unit and take 4 to 6 weeks to build. Freight, duties and installation are extra.

Related

• Smart vending machines: how connected vending machines work, with every published price.
• Kiosk vending machines: touchscreen vending platforms compared.
• Vending machine cost: starting prices, what moves the price, and landed cost.

---

Specifications

Refrigeration

• refrigerated (R290)

• refrigerated (R134a)

• ambient

Dimensions: Width: 616, Depth: 735, Height: 1970

Legs:

• fixed legs

• industrial castor wheels

Trays

• 6

Width

• 3-wide (standard) (6 selections in row)

MDB Peripherals

• cashless (QR code based payment methods only)

SKU: L180-10C

Available for distribution: true
Available for retail: true
Indicative Retail Price:

Description

The L180-10C is a standardized model of KioskForce lockers. It gives each item or order its own locked door, so it handles goods that a vending coil cannot: bulky, fragile, high-value or returnable items, and prepared orders waiting for collection. It is a cabinet without its own screen: doors open on a command from a paired kiosk, an access credential or the cloud.

L180-10C specifications

Every value below is the published configuration for this model. Anything not listed is specified on the quotation.

Specification	L180-10C
Model	L180-10C
Dimensions (W × D × H)	750 × 400 × 1,830 mm
Cells	10, each with a door-open sensor; number and sizes customisable
Lighting	Energy-efficient LED
Temperature	Ambient
Base	Industrial-grade FM levelling castor wheels, or fixed legs
Connectivity	Ethernet as standard; Wi-Fi and 4G/5G optional
Maintenance access	Emergency access through the back panel
Weight sensors	Optional, per cell, according to the value of the stored items
Price	Quoted per project (no published starting price)
Sold through distributors	Yes

No weight is published for the L180-10C. Ask for it, and for the packing dimensions, on the quotation.

Who the L180-10C is for

• Industrial sites. Secure, audited storage of PPE, tools and instruments as part of our industrial vending solutions, alongside PPE vending machines for dispense-and-return of hard hats, harnesses and gas detectors, or on its own for high-value tools.
• Prepaid and pre-ordered goods. Bakery products, boxed meals and click-and-collect orders, one per door, loaded by staff and collected by the customer.
• High-value retail items. Boxed and high-value items such as electronics, sold one per door from a kiosk screen.

Where it is deployed

A premium Sydney bakery runs what it calls Sydney’s first Bread Wall on one K180-6C touchscreen kiosk and two L180-10C cabinets, 26 illuminated compartments in total: six in the kiosk and ten in each locker. Customers select and pay at the touchscreen and collect from the door that opens, while staff refill the compartments from the bakery side. The system was supplied through our authorised Sydney distributor. Read the Bread Wall case study.

Configuration options

Compartments

The number and sizes of the compartments can be changed to fit what you store. Measure your largest item first, including its depth: the standard cabinet is 400 mm deep overall, so a box for a 16-inch pizza (at least 406 mm across) will not lie flat in it. Custom cabinets run from 100 to 2,000 mm wide, 100 to 2,000 mm high and 100 to 1,000 mm deep, with 1–10 rows of 1–10 cells. The locker configurator gives an instant estimate for a custom cabinet.

Access control

KioskForce lockers support PIN, RFID cards (MIFARE, HID and EM), dual PIN and card, QR and one-time codes, and API-triggered opening. Every access is logged in the cloud and doors can be opened remotely. Biometric login is available as an option at extra cost, quoted per project.

Weight sensors

Weight sensors can be configured per cell according to the value of the stored items. They are optional and fitted at the factory, so specify them at order; they cannot be retrofitted in the field. Weight confirms what is in a cell, not who took it, so the record is per cell. See weight sensor tracking.

Connectivity

Ethernet is standard, with optional Wi-Fi and 4G/5G. Where site Wi-Fi does not reach the position reliably, as is common outdoors, 4G is the usual choice; a 4G telemetry data plan typically costs USD 5–10 per month per machine.

Temperature

The standard cabinet is ambient. Chilled locker cells can be supplied to order as a custom build, quoted per project. For many units of the same chilled item, a refrigerated vending machine such as the KF10X22 or BG10X10 is the usual choice.

When the L180-10C is the wrong choice

• Many units of the same small item. A coil vending machine holds several units behind one motor, while a locker needs a door, a lock and a sensor for every item. For packaged snacks, drinks or consumables, a vending machine costs far less per unit stored.
• You need a screen on the cabinet. Pair it with a kiosk such as the K180-6C.
• Large or deep items in the standard cabinet. Specify deeper or larger cells instead.
• Refrigerated stock in the standard cabinet. Specify chilled cells to order.

Price, lead time and ordering

• Price: no published starting price for the L180-10C; locker cabinets are quoted per project. The locker configurator gives an instant estimate for a custom cabinet, and the K180-6C locker kiosk starts from USD 1,800, before freight, duties and installation. See vending machine cost.
• Minimum order: modified standard models can be ordered as a single unit. Fully custom designs with a new enclosure or custom software typically start at 10 units.
• Lead time: 4–6 weeks for a modified standard build, 8–12 weeks for a full custom design, plus shipping.
• Warranty and support: 12-month standard warranty covering manufacturing defects. Support is by email, or through the local distributor where one supplied the system; that distributor also handles warranty and service. On-site installation is optional and, in some regions, provided through a local distributor.

Frequently asked questions

What is the L180-10C used for?

The L180-10C is a standard 10-cell smart locker cabinet for secure, audited storage and hand-over: PPE, tools and equipment on industrial sites, high-value items one per door, and prepaid or pre-ordered goods such as bakery products. Each cell has a door-open sensor and every access is logged.

Can the L180-10C compartment sizes be customized?

Yes. The number and sizes of compartments can be customized to customer needs, and monitoring devices such as weight sensors can be configured according to the value of the stored items. Weight sensors are optional and fitted at the factory per cell.

What connectivity does the L180-10C support?

Ethernet wired connectivity as standard, with optional Wi-Fi and 4G/5G for network flexibility. Emergency access is available through the back panel for maintenance.

Does the L180-10C have its own touchscreen?

No. The L180-10C is a locker cabinet. For a touchscreen, pair it with a kiosk such as the K180-6C, which has a 21.5-inch touchscreen and six cells of its own and can connect more locker cabinets. A Sydney bakery uses one K180-6C with two L180-10C cabinets, 26 compartments in total.

Can the L180-10C be refrigerated?

The standard L180-10C is ambient. Chilled locker cells can be supplied to order as a custom build, quoted per project.

How much does the L180-10C cost?

There is no published starting price for the L180-10C; locker cabinets are quoted per project. The online locker configurator gives an instant estimate for a custom cabinet, and the K180-6C locker kiosk starts from USD 1,800 before freight, duties and installation.

Related

• Smart lockers: how smart lockers work, types by use, and published prices.
• Smart vending machines: when a vending machine fits better than a locker.
• Vending machine cost: starting prices, what moves the price, and landed cost.

---

Specifications

Refrigeration

• ambient

Dimensions: Width: 750, Depth: 400, Height: 1830

Legs:

• fixed legs

• industrial castor wheels

Trays

Width

MDB Peripherals

SKU: BG10X10

Available for distribution: true
Available for retail:
Indicative Retail Price: $1200 USD

Description

The BG10X10 is a standard-size 5-wide vending machine with a 10-inch touchscreen built into a sidecar. It is meant for positions that need a normal 5-wide machine but have no room for the extra width of a large screen. Customers browse on the touchscreen, add items to a cart and pay by QR code, card or cash. It has the lowest published starting price of our floor-standing touchscreen models, and it is robust and built to last.

BG10X10 specifications

Every value below is the published configuration for this model. Anything not listed is specified on the quotation.

Specification	BG10X10
Model	BG10X10
Dimensions (W × D × H)	1,110 × 820 × 1,975 mm
Weight	About 300 kg, before stock
Layouts	5-wide (standard, 10 selections per row), 3-wide (6), 4-wide (8) or 6-wide (12)
Trays	5 or 6
Selections	Up to 60 in the standard 5-wide, 6-tray layout
Screen	10-inch sidecar touchscreen, with shopping cart
Payment	QR code, MDB cashless (card reader), MDB cash (coin mech and note reader)
Temperature	Refrigerated (R290 or R134a) or ambient
Base	Fixed legs or industrial castor wheels
Indicative price	From USD 1,200, before freight, duties and installation
Sold through distributors	Yes

The published dimensions are for the BG10X10 as listed; confirm the cabinet size for 3-, 4- or 6-wide layouts on the quotation.

Who the BG10X10 is for

• Snack, drink and chilled-food vending on a budget. Snacks, chilled drinks and packaged chilled food, ambient or refrigerated, with a touchscreen and cart from USD 1,200.
• A standard vending bay. It fits where a normal 5-wide machine would go and adds a screen without adding the 200 mm of width the KF10X22 needs for its 22-inch screen.
• Mixed payment sites. Card, cash and QR in one machine suits public sites where some customers still pay with coins and notes.
• A wider product range with on-screen help. Over-the-counter, first-aid and similar ranges, where a screen helps the user choose, are a common fit.

Configuration options

Payment

The BG10X10 takes three kinds of payment:

• QR code. The screen generates a QR code for the order and the customer pays with a wallet app, for example WeChat Pay or Alipay. No extra reader is needed.
• MDB cashless. A card terminal over the standard MDB cashless interface, such as Nayax, Cantaloupe or VendCoin from our Australian software partner Vending on Track. You can keep an existing processor.
• MDB cash. Coin mech and note reader.

Item-level reporting comes from the machine’s own telemetry, not from the payment terminal, so the sales record shows which product was sold even on a card sale. See payment methods.

Screen features

• Shopping cart. Customers buy several items in one transaction. See shopping cart.
• Code entry. The default homepage can be set to the product selection page or to a code input page, for free-vend or code-release programs.

Refrigeration

Choose ambient, or refrigerated with R290 or R134a refrigerant; refrigerated costs more. On machines with a sidecar, the temperature controller is in the side drawer (the FAQ shows how to set it). Refrigerated KioskForce machines have a health-control block that stops sales when the cabinet goes out of temperature range, set to your food-safety rules. For fresh or chilled food, see the guide to refrigerated vending machines for fresh and healthy food.

Coils and layout

The coil type and pitch are chosen per selection so that each product drops reliably. See coil options and the planogram configurator.

Fitting it into the building

At 820 mm deep, the BG10X10 will not pass an 815 mm (32-inch) clear door opening, the minimum in the 2010 ADA Standards, without a wider door or removing the door leaf. It is 1,975 mm tall. Measure every door, lift and corner on the route before you order, and plan for the weight of the machine plus stock on the floor.

When the BG10X10 is the wrong choice

• The position is narrow. The KF6X10 is 616 mm wide and 735 mm deep.
• You want a large screen for advertising or nutrition panels. The KF10X22 has a 22-inch touchscreen.
• You need room for badge readers, extra sensors or custom dispensing. The KF10X22 has extended space behind its screen for that hardware.
• Items are bulky, fragile, high-value or come back. A locker cell suits them better than a coil. See the L180-10C locker.
• There is no floor space. A compact wall-mount vending machine costs USD 800–1,500 and mounts on the wall.

Price, lead time and ordering

• Price: from USD 1,200 per unit at the published indicative price, before freight, duties and installation. Refrigeration, payment hardware, branding and quantity move the price. See vending machine cost.
• Minimum order: modified standard models (colour, branding, payment configuration) can be ordered as a single unit. Fully custom designs with a new enclosure or custom software typically start at 10 units.
• Lead time: 4–6 weeks to build a modified standard model, 8–12 weeks for a full custom design, plus shipping.
• Power and certification: built to the electrical supply of the destination market. Tell us the market at quotation and we confirm which certification marks and test reports come with the build.
• Warranty and support: 12-month standard warranty covering manufacturing defects. Support is by email, or through the local distributor where one supplied the machine; that distributor also handles warranty and service. On-site installation is optional and, in some regions, provided through a local distributor.

Frequently asked questions

What is the BG10X10 sidecar touchscreen?

The BG10X10 is a 5-wide vending machine with an integrated 10-inch touchscreen sidecar. It adds a touchscreen for browsing, a shopping cart and QR code or cashless payment to a standard-size machine, for positions that need a normal 5-wide machine but have no room for extra screen width.

What payment methods does the BG10X10 support?

QR code-based payments, MDB cashless (credit card reader) and MDB cash (coin mechanism and note reader).

Is the BG10X10 available refrigerated?

Yes, in refrigerated (R290 or R134a) or ambient configurations, with 5-wide, 6-wide, 3-wide or 4-wide layouts and 5 or 6 trays.

How much does the BG10X10 cost?

The BG10X10 has a published indicative starting price of USD 1,200 per unit, before freight, duties and installation. Refrigeration, payment hardware, branding and quantity move the price.

How many selections does the BG10X10 hold?

The standard 5-wide layout carries 10 selections per row, so up to 60 selections with six trays. Other published layouts carry 6, 8 or 12 selections per row, on 5 or 6 trays.

Will the BG10X10 fit through a standard door?

Check first. The BG10X10 is 820 mm deep, and a machine goes through a doorway on its depth, so it will not pass an 815 mm (32-inch) clear opening without a wider door or removing the door leaf. The 735 mm deep KF6X10 will.

Related

• Smart vending machines: how connected vending machines work, with every published price.
• Kiosk vending machines: touchscreen vending platforms compared.
• Vending machine cost: starting prices, what moves the price, and landed cost.

---

Specifications

Refrigeration

• refrigerated (R290)

• refrigerated (R134a)

• ambient

Dimensions: Width: 1110, Depth: 820, Height: 1975

Legs:

• fixed legs

• industrial castor wheels

Trays

• 6

• 5

Width

• 5-wide (standard) (10 selections in row)

• 6-wide (12 selections in row)

• 3-wide (6 selections in row)

• 4-wide (8 selections in row)

MDB Peripherals

• cashless

• cash

SKU:

Available for distribution:
Available for retail:
Indicative Retail Price: $800–$1,500 USD

Description

Compact wall-mount vending machines are purpose-built for dispensing small health and personal-care products in space-constrained locations. Unlike full-size snack and beverage machines, these units are designed for restrooms, hallways, community centres, and other venues where floor space is limited but accessibility matters.

Why Wall-Mount?

• Zero floor footprint — mounts on brick or drywall, freeing floor space for foot traffic
• Discreet placement — fits in restrooms, corridors, and alcoves where a full-size machine can’t go
• Fast installation — supplied with engineering drawings for the mounting backplate; local installers can handle it
• Accessible height — mounted at a comfortable dispensing height for standing users
• Camera-free traffic counting (technical preview) — an optional millimeter wave radar counts people passing the machine without capturing images, so it can be used in restrooms

Standard Configurations

Every machine is built to order. Typical configurations include:

Feature	Options
Coil count	6 to 30+ selections, depending on product size
Screen	7” to 32” Android touchscreen (optional — machines can run screen-free with QR code only)
Payment	Free vend, QR code, SMS code, MDB cashless
Connectivity	4G cellular, Wi-Fi
Mounting	Brick, drywall, or optional floor stand
Coil pitch	Configurable per selection — mix narrow (40-50mm) for condom packets and wide (70-90mm) for test kit boxes in the same machine
Lighting	Internal LED illumination, optional external signage panel

Built for Health Programs

Our wall-mount machines power some of Australia’s largest public health vending initiatives:

• HIV self-test kit dispensing — Deployed in the HIVConnect program across 6 Australian states and in the MyTest program at 16 NSW locations
• Free sanitary product programs — 32-inch touchscreen wall-mount machines dispensing pads and tampons, funded by on-screen advertising
• Condom vending — Privacy-first dispensing for universities, nightlife venues, and community health centres

How It Works

1. User registers on a web portal (phone or computer) — answers a few questions, receives a code
2. User visits the machine — scans a QR code or enters the code on the touchscreen
3. Machine dispenses the product — motor-driven coil drops the item into the collection bin
4. Cloud backend tracks the dispense — updates inventory, logs usage against quotas

The machine itself handles dispensing and inventory. Registration, verification, and data collection happen on the cloud platform — keeping the machine fast and the user experience private.

Customisation

We manufacture these machines to your exact specification. Common customisations include:

• Branded exterior panels and screen UI
• Custom coil layouts for mixed product sizes
• Integration with your existing cloud platform or ours (Vending on Track)
• Multi-language interface
• External status indicator lights (in-stock / low-stock / out-of-service)
• Anti-tamper locking and secure mounting hardware

For where the wall-mount form factor wins, what to confirm at each position before drawings are issued, which payment options fit inside a shallow cabinet, and where wall-mount is the wrong answer, see wall-mount and compact vending machines.

Get Started

Tell us what the machine will dispense, where it will be mounted, and how many sites your program covers. We’ll configure coil counts, screen size, payment and mounting hardware to suit.

---

Specifications

Refrigeration

Dimensions: Custom — typical wall-mount units: 400–600mm (W) × 200–350mm (D) × 600–900mm (H)

Legs:

Trays

Width

MDB Peripherals
